TOP FEATURES |
||
 |
||
|
|
|
|
| REDESIGNED PLASTICS | INVERTED HYDRAULIC FRONT FORKS | UPGRADED SEAT | REBOUND ADJUSTABLE SHOCK |
|
|
||
|
REVIEWS |
||
|
||
|
|
*
|
||
|
||
| ENGINE | ||
| Engine Type | Single Cylinder, 4 Stroke, Air Cooled | |
| Displacement | 150 cc | |
| Bore x Stroke | 62 mm x 49.6 mm | |
| Compression Ratio | 9.8 : 1 | |
| Rated Output | 13.4 hp @ 9,000 rpm | |
| Fuel Supply | Carburetor, 28 mm | |
| Ignition | CDI | |
| Starter | Electric / Kick | |
| Transmission | 5-speed Manual; 1-down, 4-up | |
| CHASSIS | ||
| Front Suspension | Hydraulic, Inverted; 230 mm Travel | |
| Rear Suspension | 450 mm Spring Pre-load and Rebound Adjustable Shock; 180 mm Travel | |
| Front Brake | 220 mm Disc | |
| Rear Brake | 190 mm Disc | |
| Front Wheel / Tire | Aluminum Alloy / 70/100 - 17 | |
| Rear Wheel / Tire | Aluminum Alloy / 90/100 - 14 | |
| Frame | Cast Steel w/ Formed Steel Tube | |
| Swingarm | Steel, Box Section | |
| DIMENSIONS | ||
| Wheelbase | 51.5 inches | |
| Seat Height | 33.5 inches | |
| Ground Clearance | 11 inches | |
| Fuel Tank | 1.58 gallons | |
| Weight | 227 pounds | |
| L x W x H | 73.2 x 31 x 44 inches | |
| OTHER | ||
| Colors | White, Blue | |
| Warranty | 30-day (Parts Only) Limited Warranty Coverage (learn more) | |
|
||
|
||
